Description:
This is an era of digital “talking”, and the transition from analog to digital mixers is a trend that cannot be ignored!
Core advantages of digital mixer:
D12 digital mixer is an all-digital “professional mixer” that SPE AUDIO of entering the digital mixer market
It combines a new concept of modern digital mixer and traditional operation.
The D12 digital mixer effectively integrates the digital mixer system with innovative design and powerful DSP functions, bringing users a very professional functional experience.
Product parameters:
1、12 channels of signal input (6 channels of MIC, 2 groups of stereo, 1 group of digital input-sound card / MP3 + optical fiber
2、Input processing-Input gain adjustment (electronic gain) pre-amplification, high and low pass filtering, 4-band parameter equalization, compressor, delay, input channel sound image balance adjustment
3、MIC input adopts digital gain adjustment (participate in memory recall)
4、+48V phantom power supply (MIC channel is turned on and off independently)
5、Input and output EQ ON/OFF
6、Stereo return input
7、Quick copy function of channel parameters
8、Each channel has a multi-function menu, mute button, and monitor button
9、Each channel is equipped with 100MM electric faders, signal lights, and peak lights (8 electric faders, 1 analog fader)
10、10 signal outputs (stereo LR main output, 6 AUX outputs, 1 stereo monitor output)
11、Output processing, high and low pass filtering, 13-band parameter equalization, compressor, delay, phase
12、Auxiliary output (pre-fader, post-fader)
13、Dual-track digital recording function
14、Dual-row 3 color 12-segment level indicator
15、Built-in sound card (MP3, PC play music directly)
16、4 shortcut scene recall modes, 12 scene storage
17、Storage and recall of user parameters (can be managed on the PC side)
18、Built-in two-way dual DSP effector
19、3.2 inch 400*240 high-definition touch color screen
20、FX pedal switch interface
22、Optical fiber input and output
22、Multi-operating system control software (IOS system, WINDOWS system) Chinese and English switching display
23、Support wired network port adjustment (or external router wireless adjustment)
24、Parameter lock function
Suitable For:
*Conference rooms
*Lecture halls
*Multi-function halls
*Recording studios
*Commercial performances
